WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | DLK |
| Certification | CE, ISO 9001 |
| Model Number | WS-500M |
| Minimum Order Quantity | 1 Set |
| Price | USD 98000-110000 per Set |
| Packaging Details | Self-Transport Trailer, Protective Wrapping for Sea Freight |
| Delivery Time | 30-40 Working Days |
| Payment Terms | L/C,T/T |
| Supply Ability | 8 Sets per Month |
Product Details
| Model | WS-500M | Power Type | Hybrid Electric + Diesel |
|---|---|---|---|
| Max Cutting Force | 500 Tons | Blade Length | 1400 Mm |
| Shear Height | 300/420 Mm | Electric Motor | 74 KW 380V/3P |
| Diesel Engine | 120 HP Deutz | Fuel Runtime | 16 Hours (400L Tank) |
| Mobility | Integrated Trailer Chassis | Control | PLC + Wireless Remote |
Product Description
WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications
The WS-500M is a truly mobile scrap metal shear with a dual diesel-electric hybrid power system. Unlike conventional shears that require fixed power infrastructure, the WS-500M can operate on grid electricity when available or switch to its onboard diesel engine for remote locations without power access. The integrated trailer chassis allows rapid deployment between scrap yards.
Mobility & Power Flexibility
- Dual Power Modes: 74 KW electric motor for grid operation + 120 HP diesel engine for off-grid sites
- Seamless Power Switching: Automatic transfer between electric and diesel modes without interrupting operation
- Integrated Trailer Chassis: Highway-towable design with standard fifth-wheel or ball hitch connection
- No Foundation Required: Built-in hydraulic stabilizers deploy for level operation on any firm ground
- Quick Deployment: Ready to operate within 30 minutes of arrival on site
- Compact Container Style: 20-foot container footprint for easy transport by truck, rail, or ship
Applications
Perfect for mobile scrap processing services, temporary demolition sites, remote mining operations,base recycling, disaster cleanup operations, and multi-yard operators who move equipment between locations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | WS-500M |
| Power Type | Hybrid (Electric + Diesel) |
| Max Cutting Force | 500 Tons |
| Blade Length | 1400 mm |
| Shear Height | 300/420 mm |
| Cutting Speed | 3-4 times/min |
| Processing Capacity | 6-9 tons/hour |
| Electric Motor Power | 74 KW (380V/3P 50Hz) |
| Diesel Engine Power | 120 HP (Deutz Tier 3) |
| Fuel Tank Capacity | 400 Liters (approx. 16 hours runtime) |
| Pump Type | A4V250 |
| Hydraulic System Pressure | ≤ 26 MPa |
| Control System | PLC + Wireless Remote Control |
| Cooling System | Hydraulic Oil Cooler + Engine Radiator |
| Mobility | Integrated Trailer Chassis with Stabilizers |
| Transport Dimensions | 6200 x 2500 x 2800 mm |
| Machine Weight | 28 Tons |
Our Service
- 24/7 global technical support via phone and remote access
- One year comprehensive warranty on all components including engine
- Worldwide spare parts delivery within 72 hours
- On-site commissioning and operator training available
- Custom diesel engine options (Deutz, Perkins) available
Contact us for a mobile demonstration at your location.
