Q15A-2500ll Gantry Plate Shear Machine with 800mm Blade Length and 30*700mm Max Cutting at 4-7 Times/Min
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | Q15A-2500ll | Blade Length | 800(mm) |
|---|---|---|---|
| Max.Cutting Specifications | 30*700(mm) | Shearing Frequency | 4-7(Times/Min) |
| Motor | 2*15(Kw) | Nominal Force | 120Tons ~315Tons |
| Driven Type | Hydraulic | Power | 15KW~44kW |
| Voltage | 21.5Mpa, Customized | Automatic Grade | Semi-Automatic |
| Shearing Force | 250(ton) | Max.cutting Material | 30*700(mm) |
| Production Capacity | 10 Sets/Month | Motor Power | 2*15(KW) |
| Highlight | 800mm Blade Length Gantry Shear,30*700mm Max Cutting Plate Shear Machine,4-7 Times/Min Shearing Frequency Gantry Plate Shear |
||
Product Description
Q15A-2500ll Gantry Plate Shear Machine
This hydraulic gantry plate shear machine is engineered for processing various metal plates,
efficiently shearing them into materials of different specifications. It serves as a superior
alternative to flame cutting methods, significantly reducing operational costs while maintaining
precision and productivity.
Product Information
Model Number:
Q15-1200~Q15-3150
Certification:
SGS
Place of Origin:
Jiangsu P.R. China
Technical Specifications
Product Name:
Gantry Plate Shear
Condition:
New
Application:
Scrap Metal Processing
Nominal Force:
120Tons ~ 315Tons
Driven Type:
Hydraulic
Power:
15KW ~ 44kW
Voltage:
21.5Mpa, Customized
Color:
Customized
Automatic Grade:
Semi-Automatic
Commercial Terms
Minimum Order Quantity:
1 Set
Price:
Negotiable
Payment Terms:
30% T/T In Advance
Supply Ability:
10 Sets/Month
Delivery Time:
As Per Requirement
Packaging Details:
Seaworthy Packing
After-sales Service:
Engineers Available for Overseas Service
Detailed Model Specifications
| Model | Shearing Force (ton) | Blade Length (mm) | Max. Cutting Material (mm) | Shearing Frequency (times/min) | Motor (KW) |
|---|---|---|---|---|---|
| Q15A-1200 | 120 | 600 | 18×500 | 4-7 | 15 |
| Q15A-1600 | 160 | 600 | 20×500 | 4-7 | 18.5 |
| Q15A-2000I | 200 | 600/800 | 25×500 | 4-7 | 22 |
| Q15A-2500I | 250 | 600 | 30×500 | 4-7 | 22 |
| Q15A-2500II | 250 | 800 | 30×700 | 4-7 | 2×15 |
| Q15A-3150 | 315 | 800 | 30×700 | 4-7 | 45 |
| Q15A-4000 | 400 | 800 | 35×700 | 4-7 | 2×22 |
| Q15A-5000 | 500 | 900 | 40×800 | 4-7 | 2×45 |
| Q15B-1600 | 160 | 1200 | 16/12×1000 | 4-7 | 18.5 |
| Q15B-2000 | 200 | 1200 | 18/16×1000 | 4-7 | 22 |
| Q15B-2500I | 250 | 1200/1600 | 25/20×1000 | 4-7 | 2×18.5 |
| Q15B-3150 | 315 | 1200 | 30/25×1000 | 4-7 | 2×18.5 |
