Industrial Automatic Horizontal Paper Baler Machine with 100 Ton Compression Force PLC Control and Auto-Eject Conveyor System
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | Dalongkai |
| Certification | ISO 9001:2015, CE, SGS |
| Model Number | DLK-HAP100 |
| Minimum Order Quantity | 1 Set |
| Price | USD 12,000-20,000 / Set |
| Packaging Details | Seaworthy wooden crate with anti-corrosion protective wrapping, vacuum-sealed hydraulic components, and steel frame reinforcement |
| Delivery Time | 25-35 working days after deposit |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 12 Sets per Month |
Product Details
| Machine Type | Industrial Automatic Horizontal Paper Baler | Model | DLK-HAP100 |
|---|---|---|---|
| Compression Force | 100 Tons | Hydraulic System Pressure | 22 Mpa |
| Main Motor Power | 30 KW | Auto-Eject Conveyor Power | 3 KW |
| Eject Conveyor Length | 3000 Mm | Eject Conveyor Width | 1000 Mm |
| Bale Size | 1000 X 700 X Variable Mm | Bale Weight | 300-500 Kg |
| Cycle Time | 20-35 Seconds | Control System | PLC Automatic With HMI Touch Screen |
| Binding Method | Automatic 4-Wire Tying System | Feed Hopper Capacity | 2.5 M³ |
| Feed Opening Size | 1400 X 900 Mm | Machine Dimensions | 7500 X 2000 X 2800 Mm |
| Machine Weight | 9,500 Kg | Power Supply | 380V / 3 Phase / 50Hz |
| Oil Tank Capacity | 600 Liters | Warranty | 1 Year |
| Highlight | 100 Ton Compression Force Paper Baler Machine,PLC Control Horizontal Paper Baler,Auto-Eject Conveyor System Industrial Paper Baling Machine |
||
Product Description
Industrial Automatic Horizontal Paper Baling Machine DLK-HAP100
Product Overview
The DLK-HAP100 Industrial Automatic Horizontal Paper Baling Machine is a high-performance solution designed for medium to large-scale paper recycling operations, packaging manufacturing facilities, and distribution centers. Featuring 100 tons of hydraulic compression force and an integrated powered auto-eject conveyor system, this horizontal baler delivers efficient, hands-free baling with minimal operator intervention.
Engineered for reliability and productivity, the DLK-HAP100 combines PLC automatic control, automatic wire tying, and powered bale ejection into a streamlined workflow. The large 2.5 m³ feed hopper accommodates bulk loading, while the 100-ton compression system ensures dense, uniform bales weighing 300-500 kg each. The integrated auto-eject conveyor automatically transfers completed bales away from the machine, enabling continuous operation without pause for bale removal.
Key Features
- 100 Ton Hydraulic Compression: Powerful hydraulic system operating at 22 Mpa delivers consistent, high-density bales ideal for export shipping and long-term storage.
- Powered Auto-Eject Conveyor: 3000mm motorized ejection conveyor automatically transfers completed bales to a collection area, eliminating manual bale handling and enabling non-stop operation.
- PLC Automatic Control: Siemens PLC system with intuitive HMI touch screen interface manages all baling functions including compression cycles, wire tying, bale length measurement, and ejection sequencing.
- Automatic 4-Wire Tying: Integrated automatic wire strapping system ensures consistent, secure bale binding for safe transportation and handling.
- Large Feed Hopper: 2.5 m³ capacity hopper with 1400 x 900 mm opening accommodates bulk material loading from forklifts, conveyor systems, or manual feeding.
- Rapid Cycle Time: Fast 20-35 second cycle time enables production of 90-120 bales per shift, maximizing daily throughput for high-volume operations.
- Modular Design: Standardized component architecture facilitates maintenance access and supports future upgrades including conveyor feed integration and remote monitoring modules.
Technical Specifications
| Compression Force | 100 Tons |
| Hydraulic System Pressure | 22 Mpa |
| Main Motor Power | 30 KW |
| Auto-Eject Conveyor Power | 3 KW |
| Eject Conveyor Dimensions | 3000mm (L) x 1000mm (W) |
| Bale Size | 1000 x 700 x Variable (mm) |
| Bale Weight | 300-500 kg |
| Cycle Time | 20-35 Seconds |
| Feed Hopper Capacity | 2.5 m³ |
| Machine Dimensions | 7500 x 2000 x 2800 mm |
| Machine Weight | 9,500 kg |
Applications
The DLK-HAP100 is ideally suited for medium to large paper recycling facilities, cardboard box manufacturing plants, commercial printing operations, distribution and fulfillment centers, and municipal waste processing stations. Its automatic operation and high throughput capacity make it an excellent choice for businesses processing 8-15 tons of paper waste per day.
Customization
We offer customization including bale chamber dimensions, conveyor integration options, dust collection systems, automatic lubrication systems, and IoT-based remote monitoring and production analytics platforms. Contact our sales engineering team to configure the optimal solution for your facility.
Support and Services
Dalongkai Technology provides comprehensive support including professional installation and commissioning, operator and maintenance training, preventive maintenance scheduling, rapid spare parts supply, and 24/7 remote technical assistance. One-year warranty with extended coverage options.
FAQ
Q: Can the auto-eject conveyor be extended?
A: Yes, the ejection conveyor can be extended up to 6000mm or configured with a 90-degree turn to direct bales to a specific collection zone.
Q: What materials can the DLK-HAP100 process?
A: Cardboard, corrugated paper, office paper, newspapers, magazines, shredded paper, and mixed paper waste. PET bottles and plastic film are also processable.
Q: How many operators are required?
A: The DLK-HAP100 can be operated by a single operator for loading supervision, with the automatic cycle handling compression, tying, and ejection independently.
