Y81K-315 Hydraulic Scrap Metal Baler Machine with 600x600mm Bale Size 3000x2500x1200mm Press Box and 400-700Kg Bale Weight
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | Y81K-315 | Type | Scrap Metal Baler |
|---|---|---|---|
| Automation | Semi-Automatic | Main Cyl.Force | 315 Ton |
| Press Box Size | 3000*2500*1200(mm) | Bale Size | 600*600(mm) |
| Bale Weight | 400~700(Kg) | Motor | 90(Kw) |
| Nominal Force | 125Tons ~1200Tons | Driven Type | Hydraulic |
| Power | 15KW~270KW | Voltage | 21.5Mpa |
| Automatic Grade | Semi-Automatic | Production Capacity | 5 Sets/Month |
| Extrusion Force | 63 Tons To 400 Tons | ||
| Highlight | 600x600mm Bale Size Scrap Baler Machine,3000x2500x1200mm Press Box Hydraulic Scrap Metal Baler,400-700Kg Bale Weight Metal Baler Press |
||
Product Description
Y81K-315 Hydraulic Scrap Metal / Iron / Steel Press Machinery
The Y81 series hydraulic metal baler efficiently compresses various metal scraps including steel, copper, aluminum, stainless steel, and automotive materials into compact shapes like square columns, cylinders, or octagons. This process significantly reduces transportation costs while improving handling efficiency.
Ideal for steel plants, recycling facilities, and metal processing industries, these balers feature hydraulic operation with optional manual or PLC automatic controls. Multiple discharge methods are available including turning over, pushing out, forwarding out, and manual lifting.
Key advantages include no need for foot screw fixing and the option for diesel engine operation when electrical power is unavailable. With extrusion forces ranging from 63 to 400 tons across 10 models, productivity varies from 4 to 40 tons per shift. Both compression chamber dimensions and bale shapes can be customized to meet specific requirements.
Product Specifications
| Attribute | Details |
|---|---|
| Product Name | Y81 series hydraulic metal baler |
| Condition | New |
| Application | Scrap metal |
| Nominal Force | 125Tons ~1200Tons |
| Driven Type | Hydraulic |
| Power | 15KW~270KW |
| Voltage | 21.5Mpa, Customized |
| Color | Customized |
| Automatic Grade | Semi-Automatic |
Commercial Terms
| Term | Details |
|---|---|
| Minimum Order Quantity | 1 Set |
| Price | Negotiable |
| Payment Terms | 30% T/T In Advance |
| Supply Ability | 10set /month |
| Delivery Time | As your requirement |
| Packaging Details | Seaworthy packing |
| After-sales Service | Engineers are available to overseas service |
Technical Specifications
| Model | Main Cyl.Force(ton) | Press Box Size(mm) | Bale Size(mm) | Bale Weight(kg) | Motor(KW) |
|---|---|---|---|---|---|
| Y81F-125 | 125 | 1200*700*600 | 300*300 | 50-70 | 15 |
| Y81F-160 | 160 | 1600*1000*800 | 400*400 | 100-150 | 22 |
| Y81F-200 | 200 | 1600*1200*800 | 400*400 | 120-220 | 37 |
| Y81F-250 | 250 | 2000*1750*1200 | 500*500 | 300-500 | 60 |
| Y81F-315 | 315 | 3000*2500*1200 | 600*600 | 400-700 | 90 |
| Y81F-315 | 315 | 3500*3000*1300 | 700*700 | 600-1000 | 90 |
| Y81K-315 | 315 | 4000*3000*1300 | 700*700 | 800-1200 | 135 |
| Y81F-400 | 400 | 3500*3000*1300 | 700*700 | 800-1300 | 135 |
| Y81K-400 | 400 | 4000*3000*1300 | 700*700 | 900-1300 | 135 |
| Y81F-500 | 500 | 4000*3000*1300 | 700*700 | 900-1500 | 135 |
| Y81K-500 | 500 | 4000*3500*1300 | 700*700 | 900-1600 | 135 |
| Y81F-600 | 600 | 4000*3000*1400 | 700*700 | 1000-1700 | 180 |
| Y81K-600 | 600 | 4000*3000*1300 | 700*700 | 1100-1700 | 180 |
| Y81F-800 | 800 | 4000*3500*1400 | 700*700 | 1200-1800 | 180 |
| Y81K-800 | 800 | 4000*3500*1400 | 700*700 | 1200-1800 | 180 |
| Y81F-1000 | 1000 | 5000*3500*1500 | 700*700 | 1300-1900 | 225 |
| Y81K-1200 | 1200 | 5000*3500*1500 | 700*700 | 1400-2000 | 270 |
