75 - 110KW Hydraulic Portable Cardboard Baler With 360 Degree Rotation Grapple

Place of Origin Jiangsu P.R. China
Brand Name DLK
Model Number CB-5000 CB-6000
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details Seaworthy packing
Delivery Time 50 days
Payment Terms L/C, T/T
Supply Ability 5 sets /month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Voltage 21.5Mpa, Customized
Power 260Hp Cooler Oil-steam Heat Exchange
Nominal Force 500Tons ~600Tons Cover Area 15000*4000mm
Quality Grade A
High Light

hydraulic bale press machine

,

mobile scrap metal baler

Leave a Message
Product Description

CB Portable Baler  Automatic / Hydraulic Machine With 360 Degree Rotation Grapple









Applications


Mobile working, diesel engine driven, no power needed, which are used for scrap;
Scrap cars; other metal structures and non-ferrous metals(stainless steel, aluminum alloy, steel,
etc).of compression baling.



Mobile Scrap Car Baler are applicable in steel plants, recycling companies, ferrous &non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles) into acceptable furnace charges (shapes: cuboid, cylinder or octagon), so as to reduce cost of transportation, to increase speed of furnace charging.





Feature:



1. The work bin of machine can contain big volume and a big area of scrap materials at one time.It is especially convenient for large scraps to bale in a short time.

2. Mechanical and electrical integration of liquid control, easy to learn and operation.

3. Hydraulic drive, operation stable and high efficiency.

4. PLC control, high reliability, simple maintenance.

5. Removable style, one equipment can be used more than one yard to reduce the cost of equipment.





Technical Parameters



1

Press box size (L*W*H)

5000*2000*1200mm



2

Bale size (W*H)

800*700mm



3

Hydraulic system working pressure

25MPa



4

Total power

260HP

Cummins

5

Overall dimension

11000*3000*4000 (side wings open)

L*W*H

11000*2300*4000mm (side wings close)

L*W*H

7

Cover area

15000*4000mm

L*W

8

Operating system

Manual

Jiangyin Dehong

9

Cooler

Oil-steam heat exchange

Jinrong Cooler
